At a glance
- Model years
- 2024
- Engines
- i-FORCE automatic (278 hp); i-FORCE manual (270 hp)
- Transmissions
- i-FORCE with 8-speed AT; i-FORCE with 6-speed MT
- Transfer case (4x4 high / low)
- 1.00:1 / 2.57:1
- Wheels and tires
- 18-in. alloy wheels with 265/65R18 tires
- Fuel tank
- 18.2 gal.
Powertrain and EPA fuel economy
City/highway/combined mpg for the TRD Sport, as Toyota prints it for each drivetrain.
| Engine | 4x2 A/T | 4x4 A/T | 4x4 M/T |
|---|---|---|---|
| i-FORCE | 20/24/22 | 19/23/20 | 18/23/20 |
Engines
| Engine | Application | Power | Torque |
|---|---|---|---|
| i-FORCE | automatic | 278 hp @ 6000 rpm | 317 lb-ft @ 1700 rpm |
| i-FORCE | manual | 270 hp @ 5,400 rpm | 310 lb-ft @ 2800 rpm |
2.4-liter 4-cylinder turbocharged, DOHC 16-valve, D-4S fuel injection (i-FORCE MAX: hybrid). Displacement 2,393 cc, bore x stroke 87.5 x 99.5 mm, compression 11:1. Recommended fuel: 87-octane or higher.
Transmissions, gear ratios and axle ratios
i-FORCE with 8-speed AT
1st 4.413 · 2nd 2.808 · 3rd 1.950 · 4th 1.511 · 5th 1.274 · 6th 1.000 · 7th 0.793 · 8th 0.651 · Reverse 3.645
Axle ratio: 4x2 3.583, 4x4 3.583
i-FORCE with 6-speed MT
1st 4.784 · 2nd 2.423 · 3rd 1.443 · 4th 1.000 · 5th 0.777 · 6th 0.643 · Reverse 4.066
Axle ratio: 4x2 4.300, 4x4 4.300
Suspension, steering and brakes
- Front suspension: Independent double-wishbone front suspension with stabilizer bar and twin-tube shocks
- Rear suspension: Leaf spring rear suspension with outboard-mounted twin-tube shocks; or Multi-link rear suspension with coil springs and outboard-mounted twin-tube shock absorbers
- Steering: Electronic Power Steering (EPS); power-assisted rack-and-pinion; overall ratio 17.0 (SR5 (265/65R18 tire), TRD PreRunner, TRD Sport, TRD Off-Road, Limited); 3.25 turns lock-to-lock (SR5 (265/65R18 tire), TRD PreRunner, TRD Sport, TRD Off-Road, Limited)
- Turning radius (ft): XtraCab 22.9/24.1 (TRD PreRunner); Double Cab (Short bed) 21.1/22.2 (TRD Sport, TRD Off-Road, Limited); Double Cab (Long bed) 22.9/24.1 (TRD-Sport, TRD Off-Road)
- Brakes: front Ventilated disc, 13.4 inches; rear Ventilated disc, 13.2 inches; electronic parking brake
Dimensions by cab and bed
XtraCab (4x2 and 4x4, long bed)
- Wheelbase: 131.9 in.
- Overall length: 213.0 in.
- Inside bed length: 73.5 in.
- Inside bed depth: 20.2 in.
- Inside bed width: 53.0 in. (at tailgate 53.0 in., at accessory rail 56.4 in., between wheel wells 44.7 in.)
Double Cab, long bed (4x2 and 4x4)
- Wheelbase: 145.1 in.
- Overall length: 226.2 in.
- Inside bed length: 73.5 in.
Double Cab, short bed (4x2 and 4x4)
- Wheelbase: 131.9 in.
- Overall length: 213.0 in.
- Inside bed length: 60.3 in.
Seating: XtraCab 2 (front headroom 39.7 in., legroom 41.8 in.); Double Cab 5 (rear headroom 38.4 in., rear legroom 33.7 in.)
Running clearance and off-road angles
Toyota prints these for one trim per cab (named in parentheses), not for every trim; they are shown as printed.
| Cab and drive | Running clearance | Approach | Departure (with tow hitch) | Departure (without) | Breakover |
|---|---|---|---|---|---|
| 4x2 XtraCab | 10.8 in. | 34.4 deg (TRD PreRunner) | 21.4 (TRD PreRunner) | 25.5 deg (TRD PreRunner) | 25.5 deg (TRD PreRunner) |
| 4x4 XtraCab | Up to 10.7 in. | 32.8 deg (SR5) | 22.1 deg (SR5) | 26.2 deg (SR5) | 23.8 deg (SR5) |
| 4x4 Double Cab | 11.0 in. (TRD Off-Road) | 32.5 deg (TRD Off-Road) | 22.2 (TRD Off-Road) | 26.6 deg (TRD Off-Road) | 24.7 deg (TRD Off-Road) |
Weights, payload and towing
Ranges across trims, as Toyota prints them for each cab and drive.
| 4x2 XtraCab | 4x2 Double Cab | 4x4 XtraCab | 4x4 Double Cab | |
|---|---|---|---|---|
| Curb weight (lb), i-FORCE | 4,145-4,200 | 4,265-4,365 | 4,375 | 4,485-4,720 |
| GVWR (lb), i-FORCE | 5,605 | 5,775-6,025 | 5,605 | 5,865-6,305 |
| Max payload (lb), i-FORCE | 1,405-1,460 | 1,445-1,690 | 1,230 | 1,380-1,705 |
| Max towing (lb), i-FORCE (SR 3,500) | 6,500 | 6,400 | 6,500 | 6,400 |
| Max tongue weight (lb), i-FORCE | 650 | 640 | 650 | 640 |
Fuel capacity 18.2 gal.; engine oil 5.6 qt. (with filter); cooling system i-FORCE engine: 12.8 qt..
Reference figures from the Offroad Build Lab calculator
ORBL estimate These come from the calculator's own record for this vehicle (tacoma_trdsport_2024), not from Toyota, and are estimates for planning. Where the same quantity appears above, Toyota's figure rules.
- Reference tire
- 265/65R18 (30.6", stock)
- Tire weight (each)
- 38 lb (estimate)
- Wheel weight (each)
- 27 lb (estimate)
- Wheel bolt pattern
- 6x139.7
- 0-100 km/h
- 7.9 s (calculator engine: 2.4L I4 Turbo)
Plan a build from this vehicle
The calculator starts from ORBL's own reference figures for the vehicle, which are estimates for planning; the figures on this page are Toyota's. In the calculator, choose the 2024 Tacoma TRD Sport.
Source
- 2024 Tacoma Product Information (2024_Toyota_Tacoma_Product_Information.pdf), 15 pp. (Toyota USA Newsroom)
Everything on this page is read from Toyota's Tacoma Product Information sheet for the model year shown. Toyota prints dimensions, weights, towing and angles for groups of trims and cabs, so those tables are shown as printed, with the trim or cab Toyota names, and are not narrowed to this trim. Options and packages can change a vehicle's figures; check Toyota's current documentation or your VIN before relying on a number.
